Essential
- Auxiliary heating or primary heating
- Compatible with most floor coverings
- Perfect for dry or wet environments
- Energy-efficient alternative
- Up to 28% energy savings*
- Free of electromagnetic fields**
- Reduction of dust and allergy risks
- Does not dry out the air / ideal humidity rate
- No exposed elements / more layout possibilities
- No maintenance
- Easy to install
- Template available for each spacing mode
- Single connection point (no return to the thermostat)
- Combination of unequalled safety features
- Oxygen-free copper heating element
- Leakproof ETFE (ethylene tetrafluoroethylene) insulation
- High-density polyethylene envelope
- Protected and grounded from end to end
- UL certified in North America
- CSA approved (Canada and United States)
* In the room with the Comfort~One heated floor system.
** According to the installation method stipulated in our Installation Guide, the recorded EMF measurement is considered insignificant (between 0.25 mG and 0.5 mG).
| Floors | |
| Standard voltages: | 120 and 240 V |
| Power : | Spacing of 6.35 cm (2.5 in.) – 1.40 W/ft2 Spacing of 7.6 cm (3 in.) – 12 W/ft2 Spacing of 8.89 cm (3.5 in.) – 10.29 W/ft2 Spacing of 10.16 cm (4 in.) – 9 W/ft2 |
| Thermostat connection : | Single connection point (no return to the thermostat) |
| Non-heating cable : | 3 m (10 ft): 2 conductors and grounds |
| Minimum bend radius: | 2.54 cm (1 in.) |
| Maximum exposure temperature: | (continuous and storage) 90°C (194°F) |
| Maximum installation temperature: | 10 °C (50 °F) |
| Maximum reheater current : | 11 A |
| Maximum circuit load : | 16 A |
| Maximum circuit protection : | 20 A circuit-breaker |
| Homologations : | ULC certified in North America CSA Canada: auxiliary or primary heating. Approved for showers, dry and wet environments. |
| Warranty: | 25 years |
| Installation surface |
Floor covering
|
|||||||
| HEATING CABLE Suggested spacing |
 |
 |
 |
 |
 |
 |
 |
 |
| Plywood |
3
|
3
|
3,5
|
3,5
|
3,5
|
3,5
|
3,5
|
3,5
|
| Smooth concrete |
3
|
3
|
3,5
|
3,5
|
3,5
|
3,5
|
3,5
|
3,5
|
| Concrete panels |
3
|
3
|
3,5
|
3,5
|
3,5
|
3,5
|
3,5
|
3,5
|
| Ceramic |
3
|
3
|
3,5
|
3,5
|
3,5
|
3,5
|
3,5
|
3,5
|
| Acoustic membrane |
3
|
3
|
3,5
|
-
|
3,5
|
-
|
3,5
|
3,5
|
| Anti-fracture membrane |
3
|
3
|
3,5
|
-
|
3,5
|
-
|
3,5
|
3,5
|
| Mortar bed |
3
|
3
|
3,5
|
3,5
|
3,5
|
3,5
|
3,5
|
3,5
|
| Scratch coat (preglazed mesh) |
3
|
3
|
3,5
|
3,5
|
3,5
|
3,5
|
3,5
|
3,5
|
| Sunroom / Solarium |
2.5
|
2.5
|
3,5
|
3,5
|
3,5
|
3,5
|
3,5
|
2,5
|
|
*(preglazed mesh subfloor) |
||||||||
